CZone Touch 7 - 2.4 Supplied Parts

7
EN / CZone® Touch 7 User & Installation Manual
Figure 2. Touch 7 Connections
Supplied Parts
Figure 3. Supplied Parts
1. Display
2. Mounting bracket
3. Mounting screws x 4
4. NMEA2000 Drop Cable
5. DC Power Connector
8-32VDC
Power
USB
Ethernet
NMEA2000
