EN / CZone® Touch 7 User & Installation Manual
22
NMEA2000 Plug Pinout
Note: Image shows rear of connector where contacts are inserted.
6 ORDERING INFORMATION
Touch 7 Part Numbers and Accessories
Part Number
Description
80-911-0200-00*
CZONE TOUCH 7 KIT
80-911-0201-00
CZONE TOUCH 7 MOUNTING BRACKET KIT SPARE
80-911-0202-00
CZONE TOUCH 7 1M NMEA 2000 DROP CABLE
80-911-0203-00
CZONE TOUCH 7 POWER CONNECTOR SPARE
*Includes mounting bracket, 1M NMEA2000 drop & power connector
