D-Link AC1900 User Manual

57D-Link DIR-878 User Manual
Section 4 - Conguration
VLAN
In the Settings menu on the bar on the top of the page, click Internet, then
click the 7-"/ link.
The guest zone feature will allow you to create temporary zones that can be
used by guests to access the Internet. These zones will be separate from your
main wireless network. You may congure dierent zones for the 2.4 GHz and
5 GHz wireless bands.
Note: If Smart Connect is enabled, Guest Zone is unavailable.
Triple-Play
Status: Click to enable or disable Triple-Play VLAN functionality. This allows
you to assign dedicated VLANs for Internet, IPTV, and VOIP trac.
Priority ID: Enable or disable trac priority ID for the Internet, IPTV, and VOIP
VLANs. Higher priority ID trac takes precedence over trac with a
low priority ID tag.
If Status is enabled:
Internet VLAN ID Enter the VLAN ID for Internet trac.
IPTV VLAN ID Enter the VLAN ID for IPTV trac.
VOIP VLAN ID: Enter the VLAN ID for VOIP trac.
If Priority ID is enabled:

D-Link AC1900 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN (RJ-45) ports	4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input current	3 A
Rack mounting	No
USB ports quantity	2
DHCP client	-
Security algorithms	WPA, WPA2, WPS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Certification	FCC B\\r CE B\\r C-Tick\\r IPv6 \\r Wi Fi \\r (WPS)\\r (WMM)\\r Windows 8

Weight and Dimensions

Depth	190.4 mm
Width	246.9 mm
Height	47.2 mm
Weight	745 g
