D-Link DAP-1620 User Manual

DAP-1620 AC1300 MU-MIMO Wi-Fi Range Extender
User Manual
Installation and Connection
9. In the opened Wireless Network Connection window, select the wireless network
dlink-XXXX
4
(for operating in the 2.4GHz band) or dlink-XXXX-5GHz
5
(for
operating in the 5GHz band) and click the Connect button.
Figure 20. The list of available networks.
10. In the opened window, enter the network key (see the field Password on the back panel of
the device) in the Security key field and click the Next button.
11. Allow or forbid your PC to be discoverable by other devices on this network (Yes / No).
Figure 21. PC discovery settings.
12. Wait for about 20-30 seconds. After the connection is established, the network icon will be
displayed as a dot with curved lines indicating the signal level.
Now you can connect to the web-based interface of DAP-1620 for configuring all needed
parameters. To gain access to an external network (to the Internet), you also need to specify the
default gateway and the addresses of DNS servers.
!
If you perform initial configuration of the extender via Wi-Fi connection, note that
immediately after changing the wireless default settings of the extender you will need to
reconfigure the wireless connection using the newly specified settings.
4 See the field Wi-Fi Name (SSID) 2.4GHz on the back panel of the device.
5 See the field Wi-Fi Name (SSID) 5GHz on the back panel of the device.
Page 31 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
