Configuring via Web-based Interface
In the Security Settings section, specify security settings of your Mesh network.
8
To do this,
select the needed type of authentication
9
from the Network authentication drop-down list.
When the WPA2-PSK authentication type is selected, the following fields are displayed:
Parameter Description
Password PSK
A password for WPA encryption. Click the Show icon ( ) to
display the entered key. By default, the value of the field
Password on the back panel of the device is used.
Encryption type
An encryption method: AES.
When you have configured the parameters, click the APPLY button.
To complete your Mesh network configuration, connect the subordinate device to a LAN port of the
main device using an Ethernet cable. Wait for about 5-6 minutes. When all the settings are applied,
the POWER/WPS LED should be solid red. Then, if needed, disconnect the Ethernet cable and
move the subordinate device to its workplace.
To view data on the current state of your Mesh network, select the needed value from the
Statistics drop-down list.
• List of APs: When this value is selected, information on all devices of your Mesh network
is displayed on the page.
• List of Clients: When this value is selected, information on all clients connected to the
devices of your Mesh network is displayed on the page.
• Neighbours: When this value is selected, a connection scheme of your Mesh network
devices is displayed on the page.
Parameter Description
Network Overview / List of APs
Model
The model of a device.
Domain
The identifier which shows that a device belongs to the Mesh
network.
IP
The IPv4 and/or IPv6 address of a device.
MAC
The MAC address of a device.
Role
The short name for a Mesh network device.
MASTERAP (Master Access Point): The main device which
provides connection to the Internet.
RAP (Router Access Point): A subordinate device connected to the
main device via a cable (directly to the main one or via some
subordinate devices connected via a cable).
8 Security settings should be the same for all devices of your Mesh network.
9 The full list will be available in the next firmware version.
Page 88 of 125

D-Link DAP-1620 Specifications

General

Type	Network repeater
WPS push button	Yes
Maximum transfer distance	- m
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	WPA, WPA2, WPS
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ac
Wi-Fi data rate (max)	1200 Mbit/s
Certification	FCC, IC, CE, C-Tick, CB, UL, Wi-Fi Certified
Product color	White
Ethernet LAN (RJ-45) ports	1
AC input voltage	110-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Antennas quantity	2
Package depth	161 mm
Package width	104 mm
Package height	94 mm
Package weight	300 g
Pallet width	1100 mm
Pallet height (air)	1479 mm
Pallet height (sea)	2055 mm
Pallet gross weight (air)	267630 g
Pallet gross weight (sea)	371900 g
Quantity per pallet (air)	700 pc(s)
Quantity per pallet (sea)	1000 pc(s)
Shipping (inner) case width	229 mm
Shipping (inner) case height	192 mm
Shipping (inner) case length	497 mm
Shipping (inner) case weight	3459 g
Shipping (inner) case net weight	3000 g
Number of cartons per pallet (air)	70 pc(s)
Number of cartons per pallet (sea)	100 pc(s)
Quantity per shipping (inner) case	10 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	59 mm
Width	120 mm
Height	42 mm
Weight	139 g
