D-Link DAP-3711 - Page 39

39D-Link DAP-3711 User Manual
Section 3 - Conguration
LED1, LED2, and LED3 light up to indicate the
DAP-3711’s signal strength. The default ranges are:
LED1: -95 dBm to -1 dBm
LED2: -71 dBm to -1 dBm
LED3: -56 dBm to -1 dBm
When the signal strength is higher than -95dB
and below -71dBm, LED1 light; when the signal
strength is higher than -71dB and below -56dBm,
both LED1 and LED2 light; when the signal
strength is higher than -56dBm, all the 3 LEDs light.
LED
Conguration:
