D-Link DAP-3711 User Manual

25D-Link DAP-3711 User Manual
Section 3 - Conguration
Basic Settings
The DAP-3711 provides three main options in the black bar on the left, which are Status, Basic Settings and Tools. This section
will introduce how to navigate the Basic Settings page. In Basic settings page, there are ve tabs: Wireless, Network, QoS,
Service, and System.
After making changes, click Save to apply them.
Wireless
In the Wireless tab, you can congure the DAP-3711’s Wi-Fi and radio settings.
Toggle the button to enable or disable Wi-Fi.Wireless
Settings:
In this section, users can set up basic and advanced
Wi-Fi and radio settings.
Radio Setting:

D-Link DAP-3711 Specifications

General

5 GHz	Yes
2.4 GHz	-
Bandwidth	0.08 GHz
Frequency band	5.745 - 5.825 GHz
Channels quantity	2 channels
Fit AP mode features	Wireless distribution system (WDS)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Maximum outdoor range	5000 m
Ethernet LAN data rates	100, 1000 Mbit/s
Transmitting power (CE)	27 dBm
Maximum data transfer rate	867 Mbit/s
Security algorithms	128-bit AES
Service Set Identifier (SSID) features	SSID broadcast
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
AC input voltage	24 V
Power consumption (typical)	15 W
Placement	Pole
Certification	CE, FCC
Product color	White
LED indicators	LAN, Power, Signal strength, WLAN
Housing material	Acrylonitrile butadiene styrene (ABS)
International Protection (IP) code	IP66
Antenna type	Internal
Antenna gain level (max)	15 dBi
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	45 mm
Width	288 mm
Height	88 mm
Weight	600 g
