29D-Link DAP-X3060 User Manual
Section 3 - Conguration
VLAN
The DAP-X3060 supports VLANs. VLANs can be created with a Name and VID. Mgmt (TCP stack), LAN, Primary/Multiple SSID, and WDS connection
can be assigned to VLANs as they are physical ports. Any packet which enters the DAP-X3060 without a VLAN tag will have a VLAN tag inserted
with a PVID. The VLAN List tab displays the current VLANs.
VLAN Status:
VLAN Mode:
Save:
VID:
VLAN Name:
Untag VLAN Ports
Tag VLAN Ports:
Edit:
Delete:
Use the radio button to toggle to Enable. Next,
go to the Add/Edit VLAN tab to add or modify
an item on the VLAN List tab.
The current VLAN mode is displayed.
Click to save the updated conguration. To
make the updates permanent, click
Conguration > Save and Activate.
Displays the VID of the VLAN.
Displays the name of the VLAN.
Displays the untagged ports.
Displays the tagged ports.
Clink the icon to edit the current VLAN.
Click the icon to delete the current VLAN.
VLAN List
