D-Link DCH-M225 User Manual

21D-Link DCH-M225 User Manual
Section 2 - Product Setup
6. If the wireless network you selected is secure, you will be prompted
to enter the Wi-Fi Password.
Click Next to continue.
7. The DCH-M225 will rebroadcast the Wi-Fi connection from the
uplink router as an Extended Network. Enter an Extended Wi-Fi
network name and Extended Wi-Fi network password.
If you would like to use the same SSID and password as your uplink
router, check the box at the bottom of the screen. This will extend
the network that your router is currently broadcasting.
Click Next to continue.
8. The setup process is now complete. A summary page will appear
displaying the settings for both the connection to the Wi-Fi
Network and the Extended Wi-Fi network. It is recommended that
you make a note of this information for future reference.
Click Save to save your settings and exit the wizard.

D-Link DCH-M225 Specifications

General

Type	AV transmitter
Antenna type	Internal
Certification	FCC\\r IC\\r Wi-Fi Certified\\r CE
Product color	White
LED indicators	Yes
Maximum resolution	- pixels
Compatible products	DLNA, AirPlay
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
Audio input	1
Frequency	2400 MHz
Connector(s)	3.5mm Audio
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	110-125 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	81.6 g
Dimensions (WxDxH)	54.1 x 41.9 x 54.61 mm
