D-Link DCH-M225 User Manual

34D-Link DCH-M225 User Manual
Section 3 - Conguration
Conguring WPA/WPA2 Personal
If you did not enable wireless security during initial setup, it is recommended that you do so using the web-based conguration
utility. Establish wireless connectivity before enabling wireless security. For more information about security, refer to “Wireless
Security Options” on page 54. If you prefer WPS, proceed to “Connecting to Wireless Clients Using WPS” on page 36.
2. Simply click Log In. (The Admin Password is blank by default.)
Note: If you did not create a password, it should be left blank.
1. Log into the web-based conguration by opening a web browser
and entering http://dlinkap.local./.
3. The conguration interface will open to the Home page. Click on
the Settings drop-down menu and select Wi-Fi. Then congure
the Wi-Fi network you would like your DCH-M225 to connect to.

D-Link DCH-M225 Specifications

General

Type	AV transmitter
Antenna type	Internal
Certification	FCC\\r IC\\r Wi-Fi Certified\\r CE
Product color	White
LED indicators	Yes
Maximum resolution	- pixels
Compatible products	DLNA, AirPlay
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
Audio input	1
Frequency	2400 MHz
Connector(s)	3.5mm Audio
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	110-125 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	81.6 g
Dimensions (WxDxH)	54.1 x 41.9 x 54.61 mm
