D-Link DCH-M225 User Manual

36D-Link DCH-M225 User Manual
Section 4 - Connecting to a Wireless Network
Connecting to a Wireless Network
Connecting to Wireless Clients Using WPS
The easiest and most secure way to connect your wireless devices to the DCH-M225 is WPS (Wi-Fi Protected Setup). Most
wireless devices such as wireless adapters, media players, Blu-ray DVD players, wireless printers and cameras will have a WPS
button (or a software utility with WPS) that you can press to connect to the DCH-M225.
Refer to the user manual for the wireless client you want to connect to make sure you understand how to enable WPS. Once
you know, follow the steps below:
Step 2 - Within two minutes, press the WPS button on your wireless
client (or launch the software utility and start the WPS
process).
Step 1 - Press the WPS button on the DCH-M225 for about three
seconds. The LED will start to blink green.
Step 3 - Allow up to two minutes to connect. Once the connection
is successful the LED will be solid green and your wireless
connection will be secured with WPA2.

D-Link DCH-M225 Specifications

General

Type	AV transmitter
Antenna type	Internal
Certification	FCC\\r IC\\r Wi-Fi Certified\\r CE
Product color	White
LED indicators	Yes
Maximum resolution	- pixels
Compatible products	DLNA, AirPlay
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
Audio input	1
Frequency	2400 MHz
Connector(s)	3.5mm Audio
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	110-125 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	81.6 g
Dimensions (WxDxH)	54.1 x 41.9 x 54.61 mm
