15D-Link DCS-2670L User Manual
Section 2: Installation
Step 4:
Place the camera over the baseplate and align the nub with the hole on the camera. Attach the
camera by sliding it in the direction of the arrow. Then screw the baseplate to the camera body.
Step 6:
Adjust the angles via the camera body and rotate the silver base until you achieve your desired
viewing angle.
Step 5:
Once the camera is secured to the baseplate, use a screwdriver to fasten the screw next to the
hole at the back of the camera body.
