7D-Link DCS-2670L User Manual
Section 1: Product Overview
Hardware Overview
Front View
1 IR LEDs Illuminate the camera’s eld of view in low light environments.
2 Power Connector Plug in the included power adapter to this connector.
3 Ethernet Connector Use an Ethernet cable for a wired connection to your network.
4 Light Sensor
The IR-Cut sensor monitors lighting conditions and switches between color and
infrared modes accordingly.
5 180° Camera Lens Provides a wide-angle view and streams/records video of your environment.
6 Status LEDs Indicates the camera’s current status.
7
Microphone
Records audio from the camera's environment.
1
2 3
4
5
6
7
