7D-Link DCS-5222L User Manual
Section 1 - Product Overview
Hardware Overview
Back
1 Ethernet Port Connect 10/100 Ethernet devices such as computers, switches, and hubs
2 Audio 3.5 mm jack for audio I/O devices such as microphones and speakers
3 Reset Button Press the reset button to return the device back to it’s factory conditions
4 DI/DO Attach digital I/O devices such as alarms or motion sensors
5 Power Receptor Connects to the power adapter
1
2
3
4
5
