5D-Link DCS-5222L User Manual
Section 1 - Product Overview
Hardware Overview
Front
1
2
4
5
8
6
1 IR LEDs for night vision Used to illuminate the camera’s eld of view at night
2 Focus Adjustment Ring Enables manual adjustment of the cameras focal length
3 Passive Infrared Sensor Passive Infrared (PIR) sensor for motion detection
4 Light Sensor Detects light levels and adjusts IR-LEDS accordingly
5 Camera Lens Records video of the surrounding area
6 Microphone Records audio from the surrounding area
3
