D-Link DIR-400 - Wireless Setup (Manual)

32D-Link DIR-400 User Manual
Section 3 - Conguration
To implement Wi-Fi protection, or WCN 2.0, tick the Enable
checkbox, click either Generate New PIN or Reset PIN to
Default, and then congure the Wi-Fi settings below. Please
see the Setting Up Wi-Fi Protection (WCN 2.0 in Windows
Vista) section later in this manual for detailed conguration
information.
Check the box to enable wireless. If you do not want to use
wireless, uncheck the box to disable all wireless functions.
Service Set Identier (SSID) is the name of your wireless
network. Create a name using up to 32 characters. The SSID
is case-sensitive.
Indicates the channel setting for the DIR-400. By default the
channel is set to 6. The wireless channel can be changed to
t the channel setting for an existing wireless network or to
customize the wireless network. The Auto Channel Selection
setting can be selected to allow the DIR-400 to choose the
channel with the least amount of interference.
You can enable a Super G Mode to allow the router to communicate with other D-Link 108 G products at boosted
transmission rates.
Choosing Super G without Turbo allows you to have enhanced transfer speeds through use of Dynamic Packet Bursting,
Fast Frames and Hardware Encryption and Compression.
Choosing Super G with Dynamic Turbo allows the router to use two channels to double the data transfer rate in addition to
Dynamic Packet Bursting, Fast Frames and Hardware Encryption and Compression. However, all wireless clients must be
Turbo capable for this function to work. If a non-Turbo wireless client connects to the network, all devices on the wireless
network will transfer data at normal rates.
Wi-Fi Protected
Setup:
Enable:
Wireless:
Wireless
Network Name:
Wireless
Channel:
Super G Mode:
Wireless Setup (Manual)
If you clicked the Manual Wireless Connection Setup button, this screen will appear, allowing you to manually congure
your wireless settings.
