9D-Link DIR-400 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
WAN LED
A solid light indicates connection
on the WAN port. This LED blinks
during data transmission.
WLAN LED
A solid light indicates that the wireless
segment is ready. This LED blinks during
wireless data transmission.
Local Network LEDs
A solid light indicates a connection to an
Ethernet-enabled computer on ports 1-4.
This LED blinks during data transmission.
Status LED
A blinking light indicates that the
DIR-400 is ready.
Power LED
A solid light indicates a proper
connection to the power supply.
