5D-Link DIR-803 User Manual
Section 1 - Product Overview
1 Power LED A solid green light indicates a proper connection to the power supply. The light will blink during boot-up.
2 Internet LED A solid green light indicates a connection to your broadband modem.
3 WPS LED This LED will blink during the WPS process.
4 Wireless LED A solid light indicates that the wireless segment is ready. The light blinks during wireless data transmission.
5 LAN LEDs (1-4)
A solid green light indicates a connection to an Ethernet device, such as a computer, switch or video game
console.
Hardware Overview
LEDs
3
4
1
2
5
