DIR-882 AC2600 Wave 2 MU-MIMO Wi-Fi Gigabit Router with
3G/LTE Support and 2 USB Ports
User Manual
Overview
Back Panel
Figure 2. Back panel view.
Port Description
USB 2.0 A port for connecting a USB device (modem, storage, printer).
LAN 1-4
4 Ethernet ports to connect computers or network devices.
INTERNET
A port to connect to a cable or DSL modem or to a private Ethernet
line (it is recommended to use the cable included in the delivery
package).
RESET
A button to restore the factory defaults.
To restore the factory defaults, push the button (with the device turned
on), hold it for 10 seconds, and then release the button.
WPS
A button to set up wireless connection (the WPS function).
To use the WPS function: with the device turned on, push the button,
hold it for 2 seconds, and release. The WLAN 2.4G and WLAN 5G
LEDs should start blinking.
