DIR-882 AC2600 Wave 2 MU-MIMO Wi-Fi Gigabit Router with
3G/LTE Support and 2 USB Ports
User Manual
Configuring via Web-based Interface
Port Mirroring
On the Advanced / Port Mirroring page, you can enable the function of mirroring the router’s
ports. This function allows to copy traffic from one or several ports to the destination port to
monitor network issues with the help of traffic analysis software.
Figure 179. The Advanced / Port Mirroring page.
To enable the function, click the ENABLE button. Upon that the following settings are available on
the page.
Parameter Description
Destination port
The port of the router to which a copy of traffic from one or several
ports will be sent. Select the relevant value from the drop-down list.
Page 230 of 303
