4 Configuration
The features and functions of the D-Link Metro Ethernet Managed Switch can be configured for optimum use
through the Web-based user interface.
Web-based Management
After you log in, you will see the screen below:
Figure 4.1 – Web-based Management
The above image is the Web-based Management home page. The three main areas are the Tool Bar on top,
the Function Tree, and the Main Configuration Panel.
The Tool Bar provides a quick and convenient way for essential utility functions like firmware upgrade and
configuration management.
By choosing different functions in the Function Tree, you can change all the settings in the Main
Configuration Screen. The main configuration screen will show the current status of your Switch by clicking
the model name on top of the function tree.
At the upper right corner of the screen the username and current IP address will be displayed.
Under the username is the Logout button. Click this to end this session.
NOTE: If you close the web browser without
clicking the Logout button first, then it will be seen
as an abnormal exit and the login session will still
be occupied.
