Tool Bar > Save Menu
The Save Menu provides Save Configuration and Save Log functions.
Figure 4.2 – Save Menu
Save Configuration
Select to save the entire configuration changes you have made to the device to switch’s non-volatile RAM.
Figure 4.3 – Save Configuration
Save Log
Click Backup Log to save the log entries to your local drive. A pop-up message will prompt you for the file
path. You can view or edit the log file by using a text editor (e.g., Notepad).
Figure 4.4 – Save Log
Tool Bar > Tool Menu
The Tool Menu offers global function controls such as Reset, Reset System, Reboot Device, Configuration
Backup and Restore, System log Backup, Firmware Backup and Upgrade.
Figure 4.5 – Tool Menu
Reset System
Provides three different reset options for the Switch. All configuration settings in non-volatile RAM will reset
to factory default and the Switch will reboot.
Figure 4.6 – Tool Menu > Reset System
Select a reset method and then click Apply to reset the system.
Reboot Device
Click Reboot to restart the switch.
