D-Link DSL-124 User Manual

47D-Link DSL-124 Wireless N300 ADSL2+ Modem Router User Manual
Section 4 - Conguration
Modify PPPoA Connection Additional Settings
Protocol: This shows the current protocol being modified.
ATM VCC: The shows the current ATM VCC configuration.
Login Name: You can change the currently configured DSL account username
here.
Password: You can change the currently configured DSL account password
here.
Authentication: Select PAP, CHAP, or Auto. The default is Auto.
Connection Type: How your DSL-124 connects to your ISP. Choose either Continuous,
Connect on Demand, and Manual.
Idle Time(s): If you selected Connect on Demand, enter the amount time the
router waits if there is no activity before disconnecting.
Static IP: If you have been assigned a static IP by your ISP, enter it here.
Click Apply Changes to have your changes take effect. Click Return to discard your
changes and return to the Internet Setup page. Click Undo to revert back to the existing
settings.
PPP INTERFACE

D-Link DSL-124 Specifications

General

Wireless Standard	802.11b/g/n
Frequency Band	2.4GHz
LAN Ports	4 x 10/100Mbps
Security	WPA/WPA2
Antenna	2 x External Antennas
Wired Ports	1 x RJ-11 ADSL port
ADSL Standards	ADSL2/2+
