DSL-2640U Wireless ADSL2+ Router with Ethernet WAN Support
User Manual
Configuring via Web-based Interface
On the opened page, you can specify the following parameters:
Parameter Description
Name
A name for the group for easier identification. You can specify any
name.
Type of group
The type of the group.
NAT. The group of this type is an external connection with address
translation. It is mostly used to connect to the Internet.
Transparent bridge. The group of this type is a transparent
connection between the router's port and an external connection. It is
mostly used to connect IPTV set-top boxes.
Local. The group of this type is an internal connection of the
router's ports. It is mostly used to join devices from the LAN to an
isolated network with no access to the Internet.
LAN Ports
In this section the LAN ports and the WLAN interface of the router
are displayed.
To add an element to the group, select the relevant checkbox.
To remove an element from the group, deselect the relevant
checkbox.
WAN Interfaces
Displayed for the NAT and Transparent bridge types only.
In this section WAN connections of the router are displayed.
To add a connection to the group, select the choice of the radio
button which corresponds to this connection.
Click the APPLY button.
To edit the parameters of a group you created, select the relevant line in the table. On the opened
page, change the needed parameters and click the APPLY button.
To remove a group you created, select the checkbox located to the left of the relevant line of the
table and click the DELETE button ( ). Also you can remove a group on the editing page. When
you delete a group, ports and interfaces assigned to it are reassigned to the DEFAULT group.
