D-Link DSL-2640U User Manual

DSL-2640U Wireless ADSL2+ Router with Ethernet WAN Support
User Manual
Configuring via Web-based Interface
)/,
On the Advanced / ALG/Passthrough page, you can allow the router to use RTSP, enable the
SIP ALG and PPPoE/PPTP/L2TP/IPsec pass through functions.
SIP is used for creating, modifying, and terminating communication sessions. This protocol allows
telephone calls via the Internet.
RTSP is used for real-time streaming multimedia data delivery. This protocol allows some
applications to receive streaming audio/video from the Internet.
The PPPoE pass through function allows PPPoE clients of computers from your LAN to connect to
the Internet through connections of the router.
The PPTP pass through, L2TP pass through and IPsec pass through functions allow VPN PPTP,
L2TP and IPsec traffic to pass through the router so that clients from your LAN can establish
relevant connections with remote networks.
Figure 108. The Advanced / ALG/Passthrough page.
Page 138 of 174

D-Link DSL-2640U Specifications

Power

input voltage	100V-240V
input current	0.6A
input frequency	50 Hz - 60 Hz
output voltage	12V
output current	1A

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 1 Mbps
ADSL2+ full rate downstream	up to 24 Mbps
ADSL2+ full rate upstream	up to 1 Mbps

Wireless Transfer Rates

IEEE 802.11b transfer rates	11, 5.5, 2, and 1 Mbps
IEEE 802.11g transfer rates	6, 9, 12, 18, 24, 36, 48, 54 Mbps

Media Interface

ADSL interface connector	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface ports	four RJ-45 ports for 10/100BASE-T Ethernet connection
