DSL-2640U Wireless ADSL2+ Router with Ethernet WAN Support
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
MAC address
The MAC address of a device from the router's LAN.
IP address
The IP address of a device from the router's LAN.
To assign several fixed IP addresses to a device with a certain MAC
address, click the ADD button, and in the line displayed, enter an IP
address. A device of your LAN can have one IPv4 address and
several IPv6 addresses.
Name
Enter a name for the rule for easier identification. Optional.
Mode
Select an operating mode of the Yandex.DNS service for this rule.
Protection off: when this value is selected, the service provides
the DNS server with no restrictions on access to unsafe web sites.
Safe: when this value is selected, the service blocks access to
malicious and fraudulent web sites.
Child: when this value is selected, the service blocks access to
malicious and fraudulent web sites and blocks access to adult
content.
After specifying the needed parameters, click the SAVE button.
To edit a rule for filtering, select a relevant line of the table, in the opened window, change the
needed values and click the SAVE button.
To remove a rule for filtering, select the checkbox located to the left of the relevant rule and click
the DELETE button ( ). Also you can remove a rule in the editing window.
After completing the work with rules, click the APPLY button.
Page 170 of 174
