DSL-2740E User Manual
95
Host Enter the destination host address for
diagnosis.
NumberOfTries Number of repetitions.
Timeout Put in the timeout value.
Datasize Packet size.
DSCP Differentiated Services Code Point, You should
set a value between 0-63.
MaxHopCount Maximum number of routes.
Interface Select the interface.
Traceroute Click start traceroute.
3.4.4.4 ADSL
Choose Maintenance > Diagnostics > ADSL. The page shown in the following
figure appears. It is used for ADSL tone diagnostics.
Click Start to start ADSL tone diagnostics.
