D-Link DSL-2740E User Manual

DSL-2740E User Manual
85
Field Description
Choose RIP2 indicates the router receives RIP v2
messages.
Choose Both indicates the router receives RIP v1
and RIP v2 messages.
Send Version
The working mode for sending RIP messages. You can
choose RIP1 or RIP2.
Choose RIP1 indicates the router broadcasts RIP1
messages only.
Choose RIP2 indicates the router multicasts RIP2
messages only.
Add Click it to add the RIP interface to the Rip Config List.
Delete
Select a row in the Rip Config List and click it to
delete the row.
3.3.13 NAT
Under this menu, NAT ALG (Application Layer Gateway), NAT Exclude IP, NAT
Forwarding, FTP ALG Config and NAT IP Mapping can be performed.
3.3.13.1 NAT ALG
Choose Advanced > NAT > NAT ALG. The NAT ALG and Pass-Through page
shown in the following figure appears. Choose the NAT ALG and Pass-Through
options, and then click Apply Changes.

D-Link DSL-2740E Specifications

Data Transfer Rates

G.dmt full rate downstream	8 Mbps
G.dmt full rate upstream	1 Mbps
G.lite downstream	1.5 Mbps
G.lite upstream	512 Kbps
G.dmt.bis full rate downstream	12 Mbps
G.dmt.bis full rate upstream	12 Mbps
ADSL full rate downstream	24 Mbps
ADSL full rate upstream	1 Mbps

Media Interface

ADSL interface connector type	RJ-11
LAN interface port type	RJ-45
Ethernet connection type	10/100BASE-T
