D-Link DSL-2740E User Manual

DSL-2740E User Manual
97
The following table describes the parameters and buttons of this page.
Field Description
Error When the system is likely to result in a module
abnormity, the system generates an Error log.
Notice When the system is under attack or logged in,
or port status changes, the system generates a
Notice log.
Remote Log Host Send system log to remote host, maybe a
domain or an IP.
Save Log to File You can save current log table to a file.

D-Link DSL-2740E Specifications

Data Transfer Rates

G.dmt full rate downstream	8 Mbps
G.dmt full rate upstream	1 Mbps
G.lite downstream	1.5 Mbps
G.lite upstream	512 Kbps
G.dmt.bis full rate downstream	12 Mbps
G.dmt.bis full rate upstream	12 Mbps
ADSL full rate downstream	24 Mbps
ADSL full rate upstream	1 Mbps

Media Interface

ADSL interface connector type	RJ-11
LAN interface port type	RJ-45
Ethernet connection type	10/100BASE-T
