DSL-2740E User Manual
3
LED Color Status Description
WPS
and the client, the LED would
light steady for 5 seconds.
Blinking WPS is successfully triggered.
Off
Device is ready for new WPS
setup.
DSL
Green
Off No signal is being detected.
Blinking
The device is handshaking with
the physical layer of the office
end.
On
A connection is set up with the
physical layer of the office end.
Internet
Green
Off
The device is under the Bridge
mode or powered off.
On
A connection is set up and no
traffic is detected.
Red On
The authentication of the PPP
dial-up is failed or MER is failed
to obtain the correct IP
address.
Rear Panel
Figure 2 Rear panel
The following table describes the interface of the device.
Interface/Button Description
DSL
RJ-11 interface for connecting the host to the telephone
jack on the wall or the MODEM interface of the splitter
through a telephone line.
