Technical Specifications
DSL-X1852E
General
Device Interfaces 4 x Gigabit Ethernet LAN ports, 1 x Gigabit Ethernet WAN port, 1 x RJ-11 xDSL port,
2 x FXS VoIP ports, 1 x USB 3.0 port, IEEE 802.11 ax¹/ac/n/g/b/a wireless LAN
LED Power, Internet, 2.4GHz Wi-Fi, 5GHz Wi-Fi, USB 3.0, LAN
Antenna Type Four external antennas
Wi-Fi Data Rate 2.4GHz Up to 600Mbps
2
, 5GHz Up to 1200Mbps
2
IEEE Standard IEEE 802.11ax/ac/n/g/b/k/v/a, IEEE 802.3u/ab
Minimum Requirements Windows 10/8.1/8/7/Vista or Mac OS X 10.6 or higher, Supports Internet Explorer 10/Firefox 28.0/Chrome
28.0/Safari 6.0 and up, Network Interface Card
Functionality
Security Protocol WPA2 (Wi-Fi Protected Access), WPA3(Wi-Fi Protected Access), WPS (Wi-Fi Protected Setup)
Firewall DoS, Stateful Packet Inspection, Anti-spoofing Checking, IP/MAC Address Filtering, 1 x DMZ
QoS D-Link Intelligent QoS Technology
Speed Test Ookla SpeedTest
Software
Device Management Web UI
Physical
Dimensions 251.64 x 166.47 x 194.18 mm (9.90 x 6.55 x 7.64 in)
Weight 485.6 grams (1.073 pounds)
Power Adapter 12V/2A
Operating Temperature 5 to 40 °C
Storage Temperature -20 to 70 °C
Operating Humidity 10% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing
Certifications CE , RCM, Telepermit
Ordering Information
DSL-X1852E AX1800 Wi-Fi 6 ADSL2/VDSL2+ Modem Router with VoIP
VoIP
Ports
Power
Connector
Reset
WPS
WAN
Port
1
The DSL-X1852E may not support all of the mandatory features, established in Wave 1 of the IEEE 802.11ax specifications
2
Maximum wireless signal rate derived from IEEE Standard 802.11ax specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and
construction, and network overhead, may lower actual data throughput rate. Environmental factors will adversely affect wireless signal range.
Power
Button
USB
Port
LAN
Ports
DSL
Port
Wi-Fi
Toggle
