34D-Link DSL-X1852E User Manual
Section 4 - Conguration
Internet - Ethernet
Your DSL-X1852E is equipped with a multi-purpose Gigabit Ethernet LAN/WAN port which can
be used to connect to the Internet. This port can also be used to connect to other Ethernet
based networks. In order for your DSL-X1852E to use Ethernet, you must congure the WAN
Connection Type and related WAN settings.
Congure your
WAN connection:
Select Ethernet to congure Ethernet connection settings.
Service Number: Select a service number from the drop-down menu, or to create a new
service number for your Ethernet connection, click Add. The service
number corresponds to the congured interface prole from your
Ethernet WAN Connection Type.
VLAN Settings
Enable Vlan ID: Enable or disable VLAN settings.
Vlan ID: Enter the VLAN ID. Enter a value from 1 - 4094.
IPv4 Settings
Connection: Select the connection method for your Internet and refer to the
respective conguration page for setup information.
For Dynamic IP (DHCP) Address, refer to Connection Type:
Dynamic IP (DHCP) on page 35.
For Static IP Address, refer to Connection Type: Static IP on
page 37.
For PPPoE, refer to Connection Type: PPPoE on page 39.
For Bridge Mode, refer to Connection Type: Bridge Mode
on page 41.
