D-Link DWP-1010 User Manual

Section 3 – Configuration
D-Link DWP-1010 User Manual 27
Login
3 times is set by default
Enter a value for max failed login attempts.
Value Range: 3 - 10.
If someone tries to login the web GUI with incorrect password for more than
the defined value, a warning message “Already reaching maximum
Password-Guessing times, please wait a few seconds!” will be displayed and
subsequent logins will be ignored.
Login Timeout
Login Timeout is enabled
and set to 300 by
default.
Enable to activate the auto logout function. Specify the maximum idle time.
Value Range: 30 - 65535.
Reboot & Reset
Telnet
System Operation
Item
Value setting
Description
Reboot
Now is set as default
Select Now or Time Schedule to set up when to reboot the system. Click
Reboot to reboot the unit immediately.
Reset to Default
N/A
Click Reset to reset the device configuration to its default value.
Configuration
Item
Value setting
Description
SSH
Service Port is set to 22
by default.
Check the Enable box to activate the SSH Telnet function for connecting from LAN or
WAN interfaces.
You can set which number of Service Port you want to provide for the corresponding
service.
Value Range: 1 -65535.

D-Link DWP-1010 Specifications

General

Plug and Play	Yes
Networking standards	IEEE 802.3at, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	1000, 2500 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Product type	-
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Power source type	PoE
4G standard	LTE
SIM card type	MicroSIM
Mobile network generation	5G
Antennas quantity	6
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Sustainability certificates	CE
USB port	No
Ethernet LAN (RJ-45) ports	1
WLAN data transfer rate (max)	- Mbit/s
Cables included	AC, LAN (RJ-45)
Compatible operating systems	Andorid, iOS Windows, Mac, Linux

Weight and Dimensions

Depth	144.8 mm
Width	105.4 mm
Height	210.4 mm
Weight	760 g
