D-Link DWP-1010 User Manual

Section 1 – Product Overview
D-Link DWP-1010 User Manual 3
Hardware Overview
Bottom View
1
SIM Card Socket
Insert a 5G/LTE capable SIM card into the slot to activate 5G/LTE service.
2
PoE
PoE (power over Ethernet) connector.
3
Reset
Press for 10 seconds to reset the device to factory default settings. The Signal LED should be
on and off during reset.
4
Wi-Fi Button
Click to enable Wi-Fi. (For installation purposes only)

D-Link DWP-1010 Specifications

General

Plug and Play	Yes
Networking standards	IEEE 802.3at, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	1000, 2500 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Product type	-
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Power source type	PoE
4G standard	LTE
SIM card type	MicroSIM
Mobile network generation	5G
Antennas quantity	6
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Sustainability certificates	CE
USB port	No
Ethernet LAN (RJ-45) ports	1
WLAN data transfer rate (max)	- Mbit/s
Cables included	AC, LAN (RJ-45)
Compatible operating systems	Andorid, iOS Windows, Mac, Linux

Weight and Dimensions

Depth	144.8 mm
Width	105.4 mm
Height	210.4 mm
Weight	760 g
