D-Link DWP-1010 User Manual

Section 2 – Installation
D-Link DWP-1010 User Manual 5
Installation
Connecting the SIM Card
1. Remove the four screws on the bottom of DWP-1010 to remove the protective base.
2. Remove the six screws around the water-resistant component. Insert the SIM card according to the
orientation label on the device.

D-Link DWP-1010 Specifications

General

Plug and Play	Yes
Networking standards	IEEE 802.3at, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	1000, 2500 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Product type	-
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Power source type	PoE
4G standard	LTE
SIM card type	MicroSIM
Mobile network generation	5G
Antennas quantity	6
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Sustainability certificates	CE
USB port	No
Ethernet LAN (RJ-45) ports	1
WLAN data transfer rate (max)	- Mbit/s
Cables included	AC, LAN (RJ-45)
Compatible operating systems	Andorid, iOS Windows, Mac, Linux

Weight and Dimensions

Depth	144.8 mm
Width	105.4 mm
Height	210.4 mm
Weight	760 g
