D-Link DWP-1010 User Manual

Section 3 – Configuration
D-Link DWP-1010 User Manual 13
Setup
The DWP-1010 connects via Gigabit Ethernet interface for 5G/LTE network connection. DWP-1010 also
functions as a NAT router to provide more flexible network applications.
Network
Network Page
Item
Description
Device Mode
Set the operating mode of the unit.
Cellular
Set the parameter for cellular network.
Ethernet
Set the IP of Ethernet and DHCP service
Device Mode
Device Mode
Item
Value setting
Description
Device Mode
1. A Must-fill setting
2. By default Modem is
selected
NAT
The unit will provide a NAT service and a simple firewall for the
connected device.
Modem
The unit will pass the cellular IP to connected device via ethernnet

D-Link DWP-1010 Specifications

General

Plug and Play	Yes
Networking standards	IEEE 802.3at, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	1000, 2500 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Product type	-
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Power source type	PoE
4G standard	LTE
SIM card type	MicroSIM
Mobile network generation	5G
Antennas quantity	6
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Sustainability certificates	CE
USB port	No
Ethernet LAN (RJ-45) ports	1
WLAN data transfer rate (max)	- Mbit/s
Cables included	AC, LAN (RJ-45)
Compatible operating systems	Andorid, iOS Windows, Mac, Linux

Weight and Dimensions

Depth	144.8 mm
Width	105.4 mm
Height	210.4 mm
Weight	760 g
