D-Link DWP-1010 User Manual

Section 5 – Regulatory Information
D-Link DWP-1010 User Manual 33
Specifications
Technical Specifications
/DWP-1010
General
Device Interfaces
1 x 2.5 Gbps GE Ethernet port, LED indicator, Wi-Fi button, 1 x Micro SIM slot (push-push), Reset button
Antenna Type
4 x Internal 5G/LTE antennas
Standards
IEEE 802.3i, IEEE 802.3u, IEEE 802.3at
5G/LTE Chipset
Qualcomm SDX62
5G/LTE Standards

5G NR Sub-6 GHz

Release 16, Cat.19
5G/LTE Frequency Support

5G Mode
Downlink: Up to 3.4 Gbps
Uplink: Up to 900 Mbps

LTE Mode
Downlink: Up to 2 Gbps
Uplink: Up to 200 Mbps
5G/LTE Throughput

5G: n1, n3, n5, n7, n8, n20, n28, n38,
n40, n41, n75 (Downlink only),
n76 (Downlink only), n77, n78

LTE: B1, B3, B5, B7, B8, B20, B28, B32 (Downlink
only), B38, B40, B41, B42, B43
Physical
Hardware Version
B1
Dimension
210.4*144.8*105.4 mm
Weight
760g
Enclosure
IP67
Power Protection
± 4kV
Power Consumption
53V/0.6A Power over Ethernet
Operating Temperature
-30 to 50 °C
Storage Temperature
-40 to 70 °C
Humidity
10% to 95% non-condensing
Certification
CE
Order Information
DWP-1010
5G/LTE Outdoor CPE

D-Link DWP-1010 Specifications

General

Plug and Play	Yes
Networking standards	IEEE 802.3at, IEEE 802.3i, IEEE 802.3u
Ethernet LAN data rates	1000, 2500 Mbit/s
Ethernet LAN interface type	Multi-Gigabit Ethernet
Product type	-
Product color	White
LED indicators	Status
International Protection (IP) code	IP67
Power source type	PoE
4G standard	LTE
SIM card type	MicroSIM
Mobile network generation	5G
Antennas quantity	6
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Sustainability certificates	CE
USB port	No
Ethernet LAN (RJ-45) ports	1
WLAN data transfer rate (max)	- Mbit/s
Cables included	AC, LAN (RJ-45)
Compatible operating systems	Andorid, iOS Windows, Mac, Linux

Weight and Dimensions

Depth	144.8 mm
Width	105.4 mm
Height	210.4 mm
Weight	760 g
