D-Link DWR-111 User Manual

13D-Link DWR-111 User Manual
Section 3 - Conguration
Several dierent Internet Connection types can be selected depending upon the specications of your Internet Service Provider (ISP).
Select the Internet Connection type specied by your
Internet Service Provider (ISP). The corresponding
settings will be displayed below. Please see the
following pages for details on how to congure
these dierent connection types.
This connection can serve as a backup for your
default connection.
Enter the name of the Internet host to be used as
the backup connection.
Enter the primary DNS server.
Enter the secondary DNS server.
Set the MTU (the default value is 1500).
Manually enter the MAC address or click Clone to
copy the PC’s MAC address.
Check this check box to enable auto-reconnect.
Check this check box to disable network address
translation.
Internet Connection
Internet Connection Type
My Internet
Connection is:
Failover Internet
Type is:
Host Name:
Primary DNS Server:
Secondary DNS
Server:
MTU:
MAC Address:
Auto-reconnect:
NAT disable:

D-Link DWR-111 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
Certification	CE
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Output current	0.5 A
Output voltage	5 V
Power source type	DC
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Status, WAN, WLAN
VPN support	L2TP/PPTP
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Security algorithms	64-bit WEP, 128-bit WEP, WPA, WPA2, WPS, WPS-PBC, WPS-PIN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
USB 2.0 ports quantity	1
3G	-

Weight and Dimensions

Depth	37 mm
Width	110 mm
Height	98 mm
Weight	240 g
