HDMI Mini connected to the

TDA3x system HDMI OUT port

4. Connect an HDMI cable that is attached to a video source (for example, computer) to

the TDA3x system in port labeled HDMI IN.

HDMI Mini connected to the

TDA3x system HDMI IN port

5. Connect power to the TDA3x system.

TDA3x system connected to a

power supply
