DesignCore™ TDA3x Product Family ▪ Quick Start Guide
Document No. 00C-131 ▪ Version 1.0 ▪ Release Date: 1/17/2019
CONFIDENTIAL ▪ 28
6.1 ISS Single Camera Capture Use Case
i. At the main menu, press 5 to select ISS Use Cases.
ii. In the ISS Use-cases menu, press either 1 or d as shown below:
1: 1CH ISS capture + ISS ISP + ISS LDC+VTNF + Display
(logo and stats overlays on display)
d: 1CH ISS capture + ISS ISP + ISS LDC+VTNF + Display + No Overlays
(no logo and no stats overlays on display)
iii. For a full menu input sequence for this use case, see Tables 5 and 6 (below).
Note: D3 Engineering's rugged digital camera module was used for this example.
Menu Input
Characters
Selects Menu Option (runs with logo and stats overlays)
S
Systems Settings
2
Capture Settings
9
OV10640 DCM
5
ISS Use-cases
1
1CH ISS capture + ISS ISP + ISS LDC+VTNF + Display
Table 5. Full Menu Input Sequence for ISS Use Case with Logo
Menu Input
Characters
Selects Menu Option (runs without logo or stats overlays)
S
Systems Settings
2
Capture Settings
9
OV10640 DCM
5
ISS Use-cases
d
1CH ISS capture + ISS ISP + ISS LDC+VTNF + Display + No
Overlays
Table 6. Full Menu Input Sequence for ISS Use Case without Logo
