DesignCore™ TDA3x Product Family ▪ Quick Start Guide
Document No. 00C-131 ▪ Version 1.0 ▪ Release Date: 1/17/2019
2.0 Contents of RVP-TDA3x ADAS Development Kit
Before setting up the RVP-TDA3x ADAS Development Kit, identify all the parts listed in Table 3 (below).
Note: Contents in box may vary for other products in the TDA3x Product Family.
Assembly, Wheel Chassis, ADAS
Assembly, Camera D3, ADAS
Cable, FAKRA Jack to FAKRA Jack, 11.5
Cable, FAKRA Jack to FAKRA Jack, 16
Cable, FAKRA Jack to FAKRA Jack, 28
Screw, Button Head, M5x16mm, Black
Cable, HDMI, Mini to Full, 6ft
External Power and I/O cable
Power Supply Auto Adapter
Power Supply, RVP-TDA3x Module
Table 3. RVP-TDA3x ADAS Development Kit contents
• Input voltage range: 9VDC to 20VDC operation
• Protected to 40VDC with surges to 60VDC
• 12V nominal
• The system is reverse battery protected
• Expect no more than 1A current draw
