DesignCore™ TDA3x Product Family ▪ Quick Start Guide

Document No. 00C-131 ▪ Version 1.0 ▪ Release Date: 1/17/2019

CONFIDENTIAL ▪ 32

6.3 HDMI Capture Use Case

Note: Only the Starter Kits – TDA3 Automotive and DM50x – support the HDMI Capture UseCase.

i. At main menu, press S to select System Settings.

ii. Press 2 for Capture Settings.

iii. In Capture Settings menu, press 2 to bring up:

2: HDMI Capture 1080P60 (Not Supported in TDA2x/TDA2Ex Multi-SerDes

board)

iv. At the main menu, press 1 to select Single Camera Use-cases.

v. In the Single Camera Use cases menu, press 1 to bring up:

1: 1CH VIP capture + Display

vi. For a full menu input sequence for this use case, see Table 8 (below):

Menu Input

Characters

Selects Menu Option (runs HDMI Capture Use Case)

Systems Settings

Capture Settings

HDMI Capture 1080P60 (Not Supported in TDA2x/TDA2Ex

Multi-SerDes board)

Single Camera Use-cases

1CH VIP capture + Display

Table 8. Full Menu Input Sequence for HDMI Capture Use Case
