DAB ACTIVE DRIVER T/T 3.0 Instruction For Installation And Maintenance

ENGLISH
56
Table 8 Menu and Default Values
Menus and Default values
Description Factory parameters
Indications on the display in normal operation
A.D.
M/T 1.0
A.D.
M/T 2.2
A.D.
T/T 3.0
A.D.
T/T 5.5
Go Electric pump operating
Sb Electric pump waiting
Utility display items and settings
(keys “MODE” and “SET” 2 seconds )
SP Setting the set-point pressure ( in bar ). Default: 3 bar 3.0 bar 3.0 bar 3.0 bar 3.0 bar
Installer display items and settings
(keys “MODE” and “SET” and “–” 5 seconds )
rC Setting the rated current of the electric pump ( in A ) 0 0 0 0
rt Setting the direction of rotation 00 00 00 00
Fn
Setting the rated rotation frequency of the electric pump.
( in Hz )
50 50 50 50
od Setting the operating mode 01 01 01 01
rP Setting the pressure drop for restarting ( in bar ) 0.5 bar 0.5 bar 0.5 bar 0.5 bar
Ad
Setting the interconnection address
(necessary on sets of several electric pumps with exchange)
“- -” “- -” “- -” “- -”
Eb
Enabling the booster 02 02 02 02
Technical assistance display items and settings
(keys “MODE” and “SET” and “+” 5 seconds )
tb
Setting the reaction time of the water low block ( in s.)
10 s 10 s 10 s 10 s
T1 Running time after low pressure signal 2 s 2 s 2 s 2 s
T2 Delay time in event of shutdown conditions 10 s 10 s 10 s 10 s
GP Setting the gain of the PI proportional coefficient 1.0 1.0 0.6 0.6
GI Setting the gain of the PI integral coefficient 1.0 1.0 1.2 1.2
FS
Setting the maximum rotation frequency of the electric pump
( in Hz )
130 130 130 130
FL
Setting the minimum rotation frequency of the electric pump .
( in Hz )
0 0 0 0
Ft Setting the low flow rate threshold 15 15 15 15
CM Exchange method on sets of 2 electric pumps 01 01 01 01
AE Setting the enabling of the anti-block/anti-frost function 01 01 01 01
i 1 Setting the function of input 1 (float) 01 01 01 01
i 2 Setting the function of input 2 (set point selection) 01 01 01 01
i 3 Setting the function of input 3 (enable ) 01 01 01 01
P1
Setting the auxiliary setpoint pressure (in bar)
- depending on input 2 -
2.5 bar 2.5 bar 2.5 bar 2.5 bar
o1
Setting the function of output 1 (default value: 2; function: ON alarm )
02 02 02 02
o2
Setting the function of output 2 (default value: 2; function: ON operating )
02 02 02 02
Display items of the main values
(“MODE”key)
Fr Display of the current rotation frequency (in Hz)
UP Pressure display (in bar)
C1 Display of electric pump phase current (in A)
As
Display of the configuration status of the inverter managed by the control
unit
UE
Display of the version of the software with which the appliance is equipped
DISPLAY (keys "SET” and “–“ for 2 seconds )
UF Display of flow
ZF Display of zero flow
FM Display of the maximum rotation frequency (in Hz)
tE Display of the temperature of the power stages (in °C)
bt Display of the temperature of the electronic board (in °C)
GS Display of running status
FF Display of the log of errors and shutdowns
Manual mode (keys “SET” and “+” and “–” 5 seconds )
FP
Setting the test frequency in manual mode (in Hz)
≤ at the set FS value
40 40 40 40
UP Pressure display (in bar)
C1 Display of electric pump phase current (in A)
rt Setting the direction of rotation
UF Display of flow
ZF Display of zero flow
System reset ( keys “MODE” and “SET” and “+” and “–” )
ZF
General reset ( ZF appears when leaving reset and restarting )
