DESCRIPTION 4F243T
Power (Gross) HP (kw) 44.7 (33.3) 49.2 (36.7) 54.4 (40.6) 60 (44.7) 66 (49.2) 73 (54.4)
Rated revolution rpm 2,600
Maximum bare speed rpm 2,800
Minimun bare idling speed rpm 1,000
Fuel consumption g/HPh (g/kWh) 168 (225)
Type Vertical, water cooled, 4-cycle diesel engine
Number of cylnders 4
Total displacement cc (cu) 2,435 (146.8)
Method of Intake Turbocharger (T/C)
Bore and stroke Φ 87*102.4
Method of Combustion Common Rail Direct Injection (CRDI)
Compression ratio 17.4 : 1
Injection order 1 - 3 - 4 - 2
Injection pressure bar 1,800
Valve clearance mm Intake : 0.2, Exhaust : 0.2
Direction of rotating Counter-clockwise (View from flywheel side)
