Daedong 3F183T User Manual

6
-7
SPECIFICATIONS
DESCRIPTION 4F243T-CM3 3FT-HI4
Power (Gross) HP (kw) 70.5 (52.6) 50.0 (37.5)
Rated revolution rpm 2,700 2,300
Maximum bare speed rpm 2,850 2,450
Minimun bare idling speed rpm 1,500 900
Fuel consumption g/HPh (g/kWh) 175 (235) 170 (228)
Type Vertical, water cooled, 4-cycle diesel engine Vertical, water cooled, 3-cycle diesel engine
Number of cylnders 4 3
Total displacement cc (cu) 2,435 (146.8)
Method of Intake Turbocharger (T/C)
Bore and stroke Φ87×102.4
Method of Combustion Common Rail Direct Injection (CRDI)
Compression ratio 17.4:1
Injection order 1-3-4-2 1-2-3
Injection pressure bar 1,800
Valve clearance mm Intake : 0.2, Exhaust : 0.2
Direction of rotating Counter-clockwise (View from flywheel side)
6
디젤엔진-현대중공업용-영문판-06.indd 7 2014-09-16 오전 8:37:43

Daedong 3F183T Specifications

General

Brand	Daedong
Model	3F183T
Category	Engine
Language	English
