Daedong DK65 - Pto Clutch Switch; Pto Switch(On;Off); Horn Button; Neutral

4-8 DK65/75/80/90
628O408A
PTO CLUTCH SWITCH
(MANUAL/AUTOMATIC)
(1) PTO Clutch Switch (N) Neutral
(A) Automatic (M) Manual
Neutral
PTO is off.
Manual
PTO is on continuously.
Automatic
PTO is turned on when implement is
lowered; PTO is turned off when imple-
ment is raised.
628O409A
PTO SWITCH(ON/OFF)
IMPORTANT
Always turn the key switch to the
“OFF” position when the tractor
is shut down to avoid damage to
the electrical system.
HORN BUTTON
628O410A
Pressing the button blows the horn.
CAUTION
The horn is designed for inter-
mittent use. Continuous use of
the horn will shorten its life.
(1) Horn Button(1) PTO Switch
(A)
- OFF (B)
- ON
As a safety feature, the engine will
not start unless the PTO switch is
turned “OFF”.
NOTE
