4-10 DK65/75/80/90
628O414A
Fuel gauge indicates the amount of fuel.
Be careful to refill the fuel tank before it
becomes empty. Once the fuel tank be-
comes empty, it will be necessary to
bleed the fuel system before the engine
will restart.
(1) Fuel Gauge
FUEL GAUGE
628O420A
This lamp lights up red when the PTO is
on.
PTO LAMP
CAUTION
As a safety feature, the engine
will not start when the PTO light
is on.
This lamp lights up yellow when the 4WD
switch is in “4WD” position; indicating the
tractor is in the 4WD mode.
4WD OPERATION INDICATOR
069O456A
To Next Page
