Daedong DK65 - Tread-Rear; Treadwidth - Front; Wheels, Tires and Tread

OPERATION 5-23
WHEELS, TIRES AND TREAD
TREADWIDTH - FRONT
The front tread width is not adjustable.
Check and tighten as instructed.
MODEL
DK 65
DK 75/ 80/
90
Control range
1,406 – 1,902mm
(55.4 - 74.9in.)
1,436 – 1,734mm
(56.5 - 68.3in.)
TREAD-REAR
DK75/80/90
628O544A
DK65
628O543A
WARNING
Do not use tires larger than
specified.
28.5 ~ 34.7 kgf·m
280 ~ 340N.m
206.6 ~ 250.7 lbf.ft
Wheel nut torque
20 ~ 23 kgf·m
196 ~ 226 N.m
144.7 ~166.3 lbf.ft
WARNING
Do not use tires larger than
specified.
Rim bolt torque
28 ~ 32.5 kgf·m
274.6 ~ 318.7N.m
202.6 ~235.0 lbf.ft
Wheel nut torque
