DISCRIPTION OF OPERATING SYSTEM 4-25
628O439A
CASSETTE TAPE RECORDER
(1) Cassette
POWER SUPPLY
Turn the knob clockwise to turn the
power ON and to increase volume.
Turning the switch counterclockwise re-
duces the volume and turns the power
OFF.
WARNING
Adjust the volume so that you can
still hear the sounds from outside
while driving.
HINTS FOR AIR CONDITIONER USE
1. The air conditioning system uses the
new refrigerant HFC-134a. Using any
other type of refrigerant will cause
system failure
2. System failure will occur if the refrig-
erant is contaminated with moisture.
Repair leaks promptly and follow
proper AC service procedures.
3. Low oil will result in compressor
failure. Excessive oil will cause im-
proper cooling.
4. Compressor oil should always be
changed or refilled in proportion to the
prescribed amount of refrigerant
whenever the system is serviced or
repaired.
5. When working for prolonged periods,
allow fresh air into the cab.
* AC SYSTEM CAPACITY
WARNING
Never sleep in the cab with the en-
gine running to avoid risk of seri-
ous injury or death.
628O442A
AIR CONDITIONER
(1) Fan Speed Switch
(2) Temperature Control (3) Air Outlets
Three fan speeds are provided; “LOW”,
“MEDIUM”, and “HIGH” to control airflow.
Turning the temperature control adjusts
the cab temperature.
ADJUSTING AIRFLOW DIRECTION
The vents can be turned to direct airflow
according to personal preference.
Refrigerant
HFC-134a
0.95 ~ 1.0kg
(2.09 ~ 2.20 lb.)
Compressor oil
VCON 488
265ml
(8.96 fl. oz.)
