4-12 DK65/75/80/90
628O418A
This indicator lights up blue when the
headlamp switch is in the high-beam
position.
HIGH-BEAM INDICATOR
628O419A
PARKING BRAKE INDICATOR
This lamp lights up red when the parking
brake is on. Do not drive the tractor with
the parking brake on.
628O421A
HYDRAULIC SYSTEM WARNING LAMP
A yellow light indicates possible problems
with the hydraulic system. The light
comes on when hydraulic pressure
drops below a specified level. Possible
causes are overheating, clogged filter,
low oil level, fluid leak or improperly at-
tached equipment.
